Trotec TFC 16 E User Manual

10 EN
fan heater TFC 16 E
Maintenance
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Allow the device to cool down completely.
Warning of electrical voltage
Tasks which require the device to be opened must
only be carried out by authorised specialist
companies or by Trotec.
Cleaning the housing
Warning of electrical voltage
Never immerse the device in water!
Clean the housing with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Wipe the housing dry after cleaning.
Technical annex
Technical data
Parameter Value
Model TFC 16 E
Heating capacity
level1:
level2:
1200W
2000W
Operating range -5 °C to +25 °C
Mains connection 220 – 240 V/ 50Hz
Max. power
consumption
2000W
Nominal current
consumption
8.7A
Fusing 10A
Type of protection IPX0
Plug type CEE 7/17
Cable length 1.5 m
Sound pressure level
(distance of 1m)
60 dB(A)
Protection class
II/
Overheating
protection
65 °C
Dimensions (depthx
widthx height)
175 x 135x 228mm
Minimum distance to
walls and other
objects
A: top:
B: rear:
C: side:
D: front:
100 cm
100 cm
100 cm
100 cm
Weight 1.5kg
