EN 17
dehumidifier TTK 26 E
Overview and list of spare parts Info
The position numbers of the spare parts differ from
those describing the positions of other parts mentioned
in this operating manual.
No. Spare Part No. Spare Part No. Spare Part
1 Water tank 11 Axle 21 Right buckle
2 Front Panel 12 PCB box 22 Anion Generator
3 Filter 13 PCB 23 Display
4 Float 14 Evaporator 24 Handle
5 Water Bracket 15 Back panel 25 Top cover
6 Rubber foot pad 16 Plug cord holder 26 Humidity Sensor
7 Bottom base 17 Drainage plug 27 Left Buckle
8 Bracket 18 Air outlet 28 Condensor assembly
9 Compressor 19 Fan wheel 29 Evaporator assembly
10 Sensor Switch 20 Motor 30
