EN Operating Manual – Dehumidifier TTK 75 E 3
Technical data
Circuit diagram
Parameters Values
Model TTK 75 E
Dehumidifying capacity, max. 20 l / 24 h
Operating temperature 5-35 °C
Working range for relative humidity 30-80 %
Volume of airflow, max. 192 m³/h
Electric connection 230 V / 50 Hz
Power consumption, max. 355 W
Fuse (home) 10 A
Condensation tank 3 l
Refrigerant R410a
Amount of refrigerant 160 g
Weight 12.3 kg
Dimensions (HxDxW) 570 x 245 x 340 mm
Minimum distance from walls of other objects A: Above: 45 cm
B: Behind: 45 cm
C: Side: 45 cm
D: Front: 45 cm
Sound pressure level LpA (1 m; complies with DIN 45635-01-KL3) 42 dB(A)
