EN 5
dehumidifier TTR 57 E
Device depiction
No. Designation
1 Control panel
2 Handle
3 Air outlet
4 Colour LEDindication for humidity level
blue=humidity >70%
green=humidity 50%–70%
red=humidity<50%
5 Condensation tank
6 Air inlet with air filter
7 Power cable
8 Connection opening for condensation hose
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
To make the device easier to transport, it is fitted with a carry
handle.
Before transporting the device, observe the following:
• Switch the device off.
– Due to the follow-up time of the internal components,
the device only switches off completely after approx. 2
minutes.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Do not use the power cable to drag the device.
• Drain the remaining condensate from the device and the
condensation drain hose (see chapter Maintenance).
After transporting the device, observe the following:
• Set up the device in an upright position after transport.
• Leave the device to rest for one hour before switching it
back on. Otherwise the device could be damaged and no
longer work properly. Any warranty claims will be voided in
this case.
Storage
Before storing the device, proceed as follows:
• Drain the remaining condensate from the device and the
condensation drain hose (see chapter Maintenance).
• Empty and clean the condensation tank prior to storage.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• in an upright position where it is protected from dust and
direct sunlight
• with a cover to protect it from invasive dust if necessary
• Place no further devices or objects on top of the device to
prevent it from being damaged.
