EN 7
pedestal fan TVE 16 / TVE 18 S
Setting the fan's inclination angle
The inclination angle of the fan can be manually adjusted by up
to 30°.
1. Move the fan head forward or back so that it is slightly
inclined either to the front or to the rear. Make sure that
the fan head locks into place at the desired inclination
angle.
ð The fan's inclination angle has been set and the air will
flow out at the selected inclination angle.
Adjusting the height
Turn the height adjustment screw to be able to set the
appropriate device height.
Start-up
When positioning the device, observe the minimum distance
from walls or other objects as described in the chapter
Technical annex.
Warning
Risk of injury due to incorrect start-up!
There is a risk of injury if the protective grid is not
installed correctly around the impeller. The protective
grid must be installed correctly before the device is
switched on.
Warning
Risk of injury if protective grid is removed!
There is a risk of injury if the protective grid is removed
during operation. Do not remove the protective grid
while the device is in operation!
• Before restarting the device, check the condition of the
power cable. If there are doubts as to the sound condition,
contact the customer service.
• Only put up the device in an upright, stable position on firm
ground.
• Do not create tripping hazards when laying the power
cable or other electric cables, especially when positioning
the device in the middle of the room. Use cable bridges.
• Make sure that extension cables are completely unrolled.
• Make sure that no curtains or other objects interfere with
the air flow.
Connecting the power cable
• Insert the mains plug into a properly fused mains socket.
