Trotec TVE 25 S User Manual

EN 11
pedestal fan TVE 25 S
Maintenance
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
Cleaning the housing
Clean the housing with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Cleaning the fan blades
ü The device is switched off.
ü The power cable has been removed from the mains socket.
1. Remove the protective grid according to the instructions in
the chapter Assembly and start-up.
2. Clean the fan blades with a soft, damp and lint-free cloth.
Ensure that no moisture enters the housing. Protect
electrical components from moisture. Do not use any
aggressive cleaning agents such as cleaning sprays,
solvents, alcohol-based or abrasive cleaners to dampen
the cloth.
• Other than that, the device does not require maintenance.
Technical annex
Technical data
Parameter Value
Model TVE 25 S
Fan stages 3
Air velocity 2.0 m/s
Input voltage 220– 240 V / 50Hz
Power consumption 40W
Power cable length 1.50 m
Adjustable inclination angle 30°
Oscillation function 80°
Height adjustability 1.10 – 1.30m
Fan blade diameter 40 cm
Sound pressure level (at 1m
distance, stage 3)
57 dB(A)
Weight 5kg
Dimensions
(lengthx widthx height)
435 x 435 x 1300 mm
Minimum distance to walls and
other objects:
top (A):
rear (B):
sides (C):
front (D):
30 cm
30 cm
30 cm
30 cm
