Read and understand all instruction, warning, and danger labels.
IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND
FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .
Lea el manual de operación anexo sobre ensamblaje e inicio.
Place PTO (Blade Engage) Lever in
Off position.
Move
Throttle
to Choke
position.
Move
Throttle to
Fast (rabbit)
position.
Insert key and turn to Start position.
Release after engine starts.
Place Shift Lever in N (neutral)
position.
Fully depress the Brake Pedal.
Need Help? Call 1-888-TO-HELP-U (1-888-864-3578)
778-11488
© 2007 13AV60KG
Is the battery connected? Fresh gas in the unit?
Refer to Operator’s Manual for troubleshooting tips.
Stopping the Unit
Didn’t Start?
Place PTO (blade engage)
lever in the Off position.
Turn key counterclockwise to
Stop position and remove key.
Depress and hold Brake Pedal.
Set parking brake by pushing
Parking Brake Lever down.
Release brake pedal.
Move throttle to Slow position.
Place shift lever in N (neutral)
position.
PTO (Blade
Engage) Lever
Shift
Lever
Throttle
Ignition
Switch
Brake
Pedal
1
2
3
4
5
6
1
2
3
4
Parking
Brake
Lever

Questions and Answers

  • B
    Bradley TaylorJul 26, 2025
    How to fix Troy-Bilt 13AV60KG011 when engine fails to start?
    • D
      dana47Jul 26, 2025
      If your Troy-Bilt Lawn Mower engine fails to start, there are several potential causes. Make sure the PTO/Blade Engage knob is disengaged, the parking brake is engaged, and the spark plug wire is connected. Ensure the throttle control lever is in the FAST position, and activate the choke. The fuel tank may be empty or contain stale fuel, so fill it with fresh gas. A blocked fuel line could also be the issue, so clean it and replace the fuel filter. A faulty spark plug should be cleaned, adjusted, or replaced. Finally, if the engine is flooded, crank it with the throttle in the FAST position.
  • T
    Teresa GallowayJul 30, 2025
    Why does my Troy-Bilt 13AV60KG011 engine run erratic?
    • Z
      zmaddenJul 31, 2025
      If your Troy-Bilt Lawn Mower engine runs erratically, first deactivate the CHOKE. Check the spark plug wires, ensuring they are connected and tightened. A blocked fuel line or stale fuel could be the problem; clean the fuel line, use fresh gasoline, and replace the fuel filter. Also, check for a plugged vent in the gas cap, clearing it or replacing the cap if necessary. Drain the fuel tank and refill with fresh gasoline if there's water or dirt in the fuel system. Finally, replace the air cleaner if it's dirty.
  • J
    Jonathan BuchananAug 4, 2025
    What to do if Troy-Bilt 13AV60KG011 will not mulch grass?
    • S
      Stephanie CrawfordAug 4, 2025
      If your Troy-Bilt Lawn Mower isn't mulching grass, ensure the engine speed is set to the FAST position. Avoid mulching when the grass is wet. If the grass is excessively high, mow it first at a high cutting height, then again at the desired height, or reduce the cutting swath. A dull blade can also cause this issue, so sharpen or replace it.
  • G
    Grace LunaAug 8, 2025
    Why is my Troy-Bilt Lawn Mower engine overheating?
    • M
      Michael RodriguezAug 8, 2025
      If your Troy-Bilt Lawn Mower engine overheats, check the engine oil level and fill the crankcase with the correct amount and weight of oil. Also, ensure that airflow is not restricted by cleaning any grass clippings and debris from around the engine's cooling fins and blower housing.
  • J
    Jeremy WhiteAug 12, 2025
    How to fix uneven cut on Troy-Bilt Lawn Mower?
    • C
      Charles RodriguezAug 12, 2025
      If your Troy-Bilt Lawn Mower is producing an uneven cut, you should perform a side-to-side deck adjustment. Check if the blade is dull and sharpen or replace it if needed. Also, ensure that the tire pressure is even across all four tires.
  • S
    sharrisAug 17, 2025
    What causes Troy-Bilt 13AV60KG011 Lawn Mower engine to idle rough?
    • W
      wkingAug 17, 2025
      If your Troy-Bilt Lawn Mower engine idles roughly, replace the spark plug and set the plug gap if the spark plug is fouled, faulty, or has a gap that is too wide. Also, replace the air cleaner element if it is dirty.
  • J
    Janet CoxAug 21, 2025
    Why does my Troy-Bilt 13AV60KG011 have excessive vibration?
    • D
      Danielle JamesAug 21, 2025
      If your Troy-Bilt Lawn Mower is experiencing excessive vibration, tighten the blade and spindle if the cutting blade is loose or unbalanced. If the cutting blade is damaged or bent, replace it.

Troy-Bilt 13AV60KG011 Specifications

General IconGeneral
BrandTroy-Bilt
Model13AV60KG011
CategoryLawn Mower
LanguageEnglish
