13
7
Parts List
To order replacement
parts, contact
1-800-520-5520,
1-330-558-7220
or visit
www.troybilt.com.
1 681-04009 Impeller Assembly Complete
2 710-1054 Machine Screw, 5/16-24 x 1.0
3 711-0833B Clevis Pin,.496
4 712-0411 Hex Lock Nut, 5/16-24
5 715-0166 Spiral Pin,.156 x 1.0
6 719-0329 Flail
7 736-0119 Lock Washer, 5/16
8 742-04050 Shredder Blade
9 742-0544 Chipper Blade
10 781-0735 Retainer Clip
1 681-0133 Tongue Hitch Mount
2 681-0134A Base Hitch Mount
3 710-3001 Hex Cap Screw, 3/8-16 x.88
4 711-0299 Clevis Pin,.625 x 2.4
5 711-0835 Clevis Pin,.50 x 4.62
6 712-3017 Hex Nut, 3/8-16
7 732-0194 Spring Pin
8 736-0133 Flat Washer,.411 x 1.25 x 1.0
9 736-0169 Lock Washer, 3/8
Models 414 & 424
