25
Models 52051 and 52052
Ref. # Part # Description Qty.
TRIM HEAD ASSEMBLY
1 1910863 Shoulder Washer.................................... 1
2 1910861 Spindle Head.......................................... 1
3 1915857 Trimmer Head ........................................ 1
4 -- Trimmer String (see Ref.
1 and 2 below) ..................................... --
5 1910862 Hex Spline Washer................................. 1
6 1915220001 Wear Cup ............................................... 1
7 1915239 Washer................................................... 1
8 1904308 Hex Flange Nut, 1/2-13........................... 1
Ref. # Part # Description Qty.
Ref. # Part # Description Qty.
ACCESSORIES AND KITS
1 1904476 Trimmer String Kit, .155" (includes
24 pieces)............................................ N/I
2 1904477 Trimmer String Kit, .130" (includes
24 pieces)............................................ N/I
3 5003 Safety Goggles....................................... 1
4 1768449 Battery Charger (Electric Start Model).... 1
1
2
3
5
6
7
8
4
1
2
3
4
4
N/I Not included with unit, order separately
