24
Trimmer/Mower Parts List
1 1910823 Wheel - 6 spoke ..................................... 2
2 1915823 Wheel Stud............................................. 2
3 1915824 Wheel Mounting Bracket ........................ 2
5 1733398 Top Lock Nut, 3/8-16 ............................. 2
13 1744708 Hex Lock Nut, 5/16-18 ........................... 8
14 1111606 Hex Head Bolt, 5/16-18 x 2 .................... 2
15 1186331 Hex Flange Screw, 5/16-18 x 1............... 4
17 9901 Washer, 5/16 ID..................................... 2
Ref. # Part # Description Qty.
Ref. # Part # Description Qty.
LOWER STEERING ASSEMBLY
1
2
2
1
3
5
7
5
3
13
13
13
13
13
14
14
17
17
15
15
