Model
52067 - 5HP
OWNER’S MANUAL
Trimmer/Mower
Safety
Assembly
Features and Controls
Operation
Maintenance
Parts List
GARDEN WAY INCORPORATED
SAFETY FIRST!
Before operating this equipment, read this
Owner's Manual and the separate manual
supplied by the engine manufacturer.

Questions and Answers

  • K
    Karen RamirezAug 3, 2025
    Why does my Troy-Bilt 52067 - 5HP run poorly?
    • T
      toddrodriguezAug 3, 2025
      If your Troy-Bilt Trimmer engine runs poorly, consider these potential causes: * A bad spark plug: Inspect or replace it. * A dirty air filter: Clean or replace it. * The carburetor being out of adjustment: Consult an Engine Service Dealer to adjust the carburetor. * Stale fuel: Drain and replace the fuel. * Dirt or water in the fuel tank: Consult an Engine Service Dealer. * A clogged engine cooling system: Clean the fins.
  • B
    Beverly AdamsAug 8, 2025
    What to do if my Troy-Bilt 52067 - 5HP vibrates?
    • D
      Dawn FosterAug 8, 2025
      Several factors may cause your Troy-Bilt Trimmer to vibrate: * A loose trimming head mounting bolt: Tighten the bolt. * Substantially different line lengths: Adjust the lines to approximately equal lengths. * Loose nuts or bolts: Check all bolts and nuts, including engine bolts. * A broken spindle head or trimmer head: Replace the broken part.
  • L
    Larry AllisonAug 14, 2025
    Why is my Troy-Bilt Trimmer overheating?
    • W
      William GoldenAug 14, 2025
      If your Troy-Bilt Trimmer engine overheats, it could be due to: * A clogged engine cooling system: Clean the air cooling areas and behind the debris shield. * Carburetor out of adjustment: Adjust the carburetor. See Engine Service Dealer.
  • S
    Sharon ZimmermanAug 18, 2025
    Why does my Troy-Bilt 52067 - 5HP have poor mowing performance?
    • F
      Frank GuerraAug 18, 2025
      If your Troy-Bilt Trimmer has poor mowing performance, it could be due to: * Line length being too short or too long: Adjust the line length to 18" long. When less than 1/2 this length, replace the line. * Cutting height being too high or low for the height of grass being cut: Adjust cutting height to approximately 1/3 of the length of the grass. * Engine not set at FAST speed: Move Engine Throttle Lever to FAST (Rabbit).
  • M
    Michelle StewartAug 25, 2025
    What to do if Troy-Bilt Trimmer Head does not retain height setting?
    • J
      Joseph JamesAug 25, 2025
      If the trimmer head on your Troy-Bilt Trimmer does not retain its height setting, it may be because: * Head bolts may be loose: Tighten head bolts to 75 in/lbs. * Head is worn: Replace head assembly.
  • A
    adammejiaOct 29, 2025
    How to fix a Troy-Bilt 52067 - 5HP Trimmer that won't start?
    • G
      Gina SolomonOct 29, 2025
      If your Troy-Bilt Trimmer engine doesn't start, here are several possible causes: * The spark plug wire might be disconnected: Reconnect it. * The spark plug might be defective or incorrectly gapped: Inspect or replace it. * The fuel tank might be empty: Add fuel. * The carburetor or fuel line might be dirty: Clean them. * The air cleaner might be dirty: Clean or replace it. * The carburetor might be out of adjustment: See an Engine Service Dealer to adjust it. * The engine might be flooded: Wait several minutes before starting. * The Engine Throttle Lever might be in the incorrect position: Move it to the FAST position. * The gasoline might be stale: Drain the old fuel and add fresh fuel. * The Engine Throttle Lever might be defective or there might be dirt or water i...

Summary

Section 1: Safety

General Operation Safety

Detailed safe operation practices for walk-behind mowers.

Slope Operation Safety

Safe practices for operating the trimmer/mower on slopes.

Child Safety Precautions

Safety precautions regarding children during operation.

Fuel Handling Safety

Safety guidelines for handling gasoline and fuel.

Safety Decals

Information about keeping safety decals clean and legible.

Section 2: Assembly

Inspection and Unpacking

Checking for damage, unpacking unit, and comparing parts.

Handlebar and Control Installation

Steps for installing handlebars and throttle control lever.

Pre-Operation Checks

Procedures for adding motor oil and checking trimmer head hardware.

Section 3: Features and Controls

Operating Symbols

Explanation of various symbols used on the unit.

Key Features and Controls

Details on trimmer head control, cutting height, handlebar, throttle, starter, primer, and shield.

Section 4: Operation

Pre-Start Checklist

Essential checks before starting the engine.

Fueling and Adjustments

How to fill the fuel tank and adjust cutting/handlebar height.

Trimmer Line and Control Operation

Guidance on trimmer line selection and using the control bail.

Starting and Stopping Procedures

Steps for starting the engine and trimmer head, and shutting down.

Mowing Techniques and Settings

Tips for cutting, walking speed, throttle, and mowing direction.

Section 5: Maintenance

Maintenance Schedule and Adjustments

Covers maintenance schedule, trimmer head engagement, and belt tension.

Component Servicing

Procedures for removing/replacing trimmer head, drive belt, and cleaning engine.

Lubrication and Storage

Guidance on lubricating parts and compact storage.

Cleaning and Specific Maintenance Tasks

Covers mower cleaning, spark plug, arrester screen, engine, carb/throttle, and off-season storage.

General Engine Maintenance

Routine engine maintenance including oil and air cleaner service.

Trimmer Line Replacement

Step-by-step guide for replacing trimmer lines.

TROUBLESHOOTING

Engine Issues

Troubleshooting for engine starting, running, and overheating problems.

Performance and Operation Issues

Troubleshooting for engine shut-off, mowing performance, and vibration.

Trimmer Head Issues

Solving problems with trimmer head line retention and height setting.

CUSTOMER SERVICE INFORMATION

Owner and Unit Information

Details on registration, warranty, and model/serial numbers.

Support and Parts

Information on obtaining technical service, replacement parts, and engine repair.
