Troy-Bilt Colt FT - Assembly & Set-Up; Contents of Carton; Assembly

Assembly & Set-Up
3
7
Assembly
References to the right and left side of tiller are determined from
behind the equipment in the operating position.
Recommended Tools for Assembly
 ⁄” open-end wrench
 ⁄” open-end wrench
 Clean oil funnel
 
specifications and quantity required.
Handle
 
Forward Clutch Cable
Figure 1-1
NOTE: Be sure not to kink cables while attaching.
2. Hook the “Z” end of the forward clutch cable into the tine

Figure 1-2
3. Remove the hex screw and bell washer from the right side of
the frame. Hold the cable guide bracket on the left side of frame

2
1
3
Hex Screw
Hex Screw
Bell Washer
Bell Washer
Cable Guide
Bracket
Handle
Figure 1-3
 
5. Insert the bolt through the cupped washer, frame, handle
and into the cable guide bracket (note the notch in the
cable guide bracket goes over the flange on the frame.)

Contents of Carton
     
   
