19
Model CSV 204
Ref
No.
Part Number Description
1. 781-0677-0637 Chain Case - LH
2. 781-0676-0637 Chain Case - RH
3. 954-0457 V-Belt
4. 748- 0313 Spacer
5. 941-0413 Hex Flange Bearing
6. 936-0336 Flat Washer
7. 913-0422 Chain
8. 710-0896 TT Screw, 1/4-14 x 0.625”
9. 710-0603 Hex Washer Screw, 5/16
10. 618-0256† Chipper Shredder Trans. Ass’y.
11. 611- 0 0 63 Axle Assembly
12. 734-1804A Wheel, 6.0 x 2.0
13. 750-1042 Spacer
14. 912- 0431 Flange Lock Nut, 3/8-16
15. 710-0521 Hex Cap Screw, 3/8-16 x 3.0
16. 681-0088-0638 Bracket Assembly
17. 736-0931 Flat Washer, .203 ID x.403 OD
18. 937-3000 Grease Fitting, 3/16
19. 681-0087-0638 Bracket Assembly
20. 914-0104 Cotter Pin
21. 749 -1095-0638 Upper Handle
22. 1539 -019 Push Nut
23. 911- 0737 Stud Pin, .250 x 1.75
24. 746-0714 Clutch Cable - 56”
25. 731-1735 Upper Clutch Cover
26. 731-0620A Drive Lever
27. 731-1736 Lower Clutch Cover
28. 710- 0841 Screw, #10-12 x.750
Ref
No.
Part Number Description
29. 731-1059 Mounting Cable Cap
30. 710-1331 Screw, #10-16 x 1.25
31. 710-0805 Hex Cap Screw, 5/16-18 x 1.50
32. 936-0451 Shldr. Washer, .320 ID x.93 OD
33. 712-3004A Hex Flange Lock Nut, 5/16-18
34. 726- 0214 Push Cap
35. 712-0380 Hex Nut, 1/4-28
36. 781-0647-0638 Discharge Chute Bracket
37. 710-3008 Hex Cap Screw, 5/16-18 x.75
38. 747-0815 Eye Bolt
39. 710-0896 Hex Washer Screw, 1/4-14 x.625
40. 731-1646 Belt Cover
41. 719- 0359 Engine Mounting Adapter
42. 936-0264 Flat Washer, .330 ID x.630 OD
43. 741-0487C Flange Bearing, .632 ID
44. 736-0366 Flat Washer, 5/8 ID x 1.0 OD
45. 710-3103 Hex Cap Screw, 5/16-18 x 1.75
46. 749-1094-0638 Lower Push Handle
47. 710-0502A Screw, 3/8-16 x 1.25
48. 710-0604A Hex Wash. Screw, 5/16-18 x.625
49. 941-0413 Hex Flange Bearing, .631 x.720
50. 681-0097A-0638 Frame Assembly
51. 781-0700-0637 Axle Bracket
52. 781-0697-0637 Transmission Cover
53 747-0924 Lock Pin
54 932-0306 Compression Spring
55 725-0157 Cable Tie
— 723-0400 Safety Glasses (Not Shown)
† See Next Page for transmission breakout
To Next Page
