Parts List 31
Models 664D, 665B & E666M
ENGINE, SUPPORT BRACKETS, PULLEYS, BELTS, BELT COVER
1 710-0539 Screw, 3/8-24 x 1.75 (A) .................... 1
GW-9572 Screw, 5/16-24 x 1.125
(B)................. 1
2 1917326 Bracket, Clutch Cable .......................... 1
3 736-0119 Lockwasher–5/16................................ 6
4 710-0107 Hex Hd. Screw, 5/16-24 x 1/2 ............. 2
5 777S30651 Decal, Hot Surfaces/Belt Warning ....... 1
6 1916659 Cover .................................................. 1
7 712-3004A Flange Lock Nut, 5/16-18.................... 2
8 1108841 Key, 3/16 x 1-1/2
(B)........................... 1
9 GW-1138-1 Shim ................................................... 1
10 619-04015 Pulley, Engine Drive (A) ...................... 1
191652 Pulley, Engine Drive (B) ...................... 1
11 GW-9944 Belleville Washer
(B)........................... 2
12 GW-9572 Hex Hd. Screw, 5/16–24 x 1-1/8 ......... 1
13 710-3103 Hex Hd. Screw, 5/16–18 x 2 ............... 1
14 1918731 Reverse Idler Arm ............................... 1
15 1916535 Pulley, Reverse Idler ........................... 1
16 736-0159 Flat Washer, 5/16................................ 2
17 1916725 Belt Guide, Wire Formed .................... 1
18 710-0117 Hex Head Screw, 5/16-24 x 1.............. 1
19 1917746 Washer, Shoulder ............................... 1
20 736-3078 Washer, Flat, 1-1/8
(B)........................ 3
21 1916728 Spring, Reverse Return....................... 1
22 1916522 Transmission Pulley............................ 1
23 GW-1440 Support Washer.................................. 1
24 1918812 Reverse Clutch Belt............................. 1
25 1909404 Forward Clutch Belt............................. 1
26 1900396 Self-tapping Screw, #10-32 x 1/2, ...... 4
27 GW-20339 Guard, Belts/Pulleys............................ 1
28 712-4063 Hex Flange Nut, 5/16–18..................... 4
29 1186329 Hex Flange Screw, 5/16-18 x 3/4* ...... 4
30 1916797 Engine Support Bracket, left side ........ 1
31 1916796 Engine Support Bracket, right side...... 1
32 736-0452 Bell Washer
(A)................................... 1
35 710-0395 Hex Hd. Screw, 5/16–18 x 2-1/4 ......... 5
36 777I20942 Decal, Stabilization.............................. 1
37 1918774 Mounting Bar ...................................... 2
38 710-1260 Hex Flange Screw, 5/16-18 x .75 ........ 4
39 710-0805 Hex Hd. Screw, 5/16-18 x 1-1/2*........ 1
40 736-0275 Flat Washer, 5/16'............................... 1
41 1918846 Belt Guide, Pony ................................. 2
42 GW-55088 Pivot Bushing...................................... 2
43 714-04029 Key, .188 x 1.75
(A) ............................ 1
44 712-3010 Hex Nut, 5/16-18................................. 2
45 1917746 Washer, Shoulder (A) ......................... 2
46 1918744 Idler Arm, Forward Tiller Direction...... 1
47 1767754 Screw, self tapping, #10-24 ................ 1
48 1916727 Spring ................................................. 1
49 712-3000 Hex Locknut, 5/16-18 ......................... 1
50 GW-9090 Idler Pulley, Forward .......................... 1
51 710-0347 Screw, 3/8-16 x 1-3/4 ......................... 1
52 712-0158 Hex Lock Nut, 5/16-18 ........................ 1
53 1754128 Screw, 1/4-20 x 3/4 ............................ 1
54 736-0463 Flat Washer–1/4.................................. 1
REF. PART
No. No. DESCRIPTION QTY.
REF. PART
No. No. DESCRIPTION QTY.
* Specify GRADE 5 if ordering part locally.
** See your local authorized engine service dealer for engine parts or
service. Refer to engine nameplate for engine type and code
information.
(A) For Models 664D & E666M
(B) For Model 665B
