Troy-Bilt TB30 - Attaching The Seat

11Section 3 — ASSembly & Set-Up
Figure 3-5
3. Align the seat bracket in place over the holes from where
the self-tapping bolts were removed, as shown in Figure

 Using a /-inch drive ratchet with a /
seat bracket with the self-tapping bolts removed in step 2.

Figure 3-6
CAUTION: Do not use any type of power tool (e.g.
impact gun or electric drill with nut driver attached)
when tightening the self-tapping bolts to attach the
seat bracket.
5. Position the seat assembly over the seat mounting bracket,
aligning the holes provided.
5. 

 Remove the pedestal cap mount hex screw factory

Retain the screw for later instructions.
7. 
rotate to the right to clip into place. Secure the pedestal
with the hex screw (2) previously removed. See Figure 3-3.
1
2
Figure 3-3
Attaching The Seat
If the seat for your tractor was not attached at the factory, follow
the applicable instructions below to attach it.
 Remove the shoulder bolts and lock nuts from the seat
mounting bracket included in your hardware pack. See

Figure 3-4
2. Remove the two self-tapping bolts factory installed on the
tractor. See Figure 3-5.
