Troy-Bilt TB360 User Manual

Assembly & Set-Up
3
9
Contents of Carton
• OneLawnMower • OneGrassCatcher • OneBottleofOil
• OneLawnMowerOperator’sManual • OneEngineOperator’sManual • OneSideDischargeChute
• OneFuse†
b
Figure 3-2
2. RemovetheT-boltsfromthehandlebracketsasshownin
Figure3-3.
Figure 3-3
NOTE: PleasebeawarethatthisOperator’sManualcoversboth
thelowandhighwheelmodelsofthismower.Whilethissection
illustratesthehighwheelmodel,theinstructionsandfeatures
areequallyapplicabletothelowwheelmodelaswell,unless
otherwisenoted.
Assembly
NOTE: Thisunitisshippedwithoutgasolineoroilintheengine.
Fillupwithgasolineandoilasinstructedintheaccompanying
enginemanualBEFOREoperatingyourmower.
Handle
1. Removeanypackingmaterialwhichmaybebetween
upperandlowerhandles.
a. Removewingnutsandcarriageboltsfromhandle
asshowninFigure3-1.Donotloosenorremove
adjacenthexheadscrews.
a
a
Figure 3-1
b. Whilestabilizingmowersoitdoesn’tmove,pivot
upperhandleupasshowninFigure3-2.Donot
crimpcableswhileliftingthehandleupandmake
suretheygoontheoutsideofthehandle.
†IfEquipped

Troy-Bilt TB360 Specifications

General

Engine Brand	Briggs & Stratton
Engine Displacement	163cc
Cutting Width	21 inches
Cutting Height Range	1.25 to 3.75 inches
Deck Material	Steel
Mulching Capability	Yes
Rear Bag Capability	Yes
Side Discharge	Yes
Oil Capacity	20 oz
Starting System	Recoil
Warranty	2 years limited
