E32
PARTS LIST
ENGINE PARTS - MODELS TB425CS, TB475SS & TB490BC
4-CYCLE GAS TRIMMERS
Item
Part No. Description
45 791-181247 Palnut
46 753-1199 Recoil Pulley
47 753-04286 Recoil Spring
48 791-182366 Nut Clip
49 791-181079 Pull Handle
50 791-611061 Rope Guide
51 791-613103 Rope
52 791-181020 Starter Housing Screw
53 753-1237 Starter Housing Assembly (includes 45-52)
54 791-182396 Clutch Washer
55 753-1238 Clutch w/Spacer
56 791-153592 Clutch Drum
57 753-1239 Clutch Cover
58 791-145569 Anti-Rotation Screw
59 753-1240 Screw
60 753-1241 Nut
61 791-181345 Clutch Cover Screw
62 753-04298 Ignition Module with Screws
63 791-181065 Spacer
64 753-04299 Flywheel
65 791-182743 Shroud Assembly (includes 86)
66 791-182376 Crankcase Assembly (includes 67 & 68)
67 791-182375 90° Elbow
68 791-182379 Breather Hose
69 791-181015 Cam Gear
70 753-1242 Cam Follower Set
71 791-181013 Cam Bracket
72 791-181012 Cam Bracket Screw
73 791-181040 Valves, Intake and Exhaust
74 791-182374 Cylinder Gasket
75 791-181018 Oil Pan Gasket
76 791-182377 Oil Pan (includes 75 & 77)
77 791-181020 Oil Pan Screw
78 753-04041 Dipstick Assembly ((ncludes 79)
79 791-182290 O-Ring
80 791-181009 Connecting Rod
81 791-181008 Wrist Pin Button
82 753-1243 Piston (includes 84)
83 791-181006 Wrist Pin
84 791-182295 Piston Ring Set
85 791-181861 Shroud Screw
86 791-182537 Grommet
87 791-182360 Heat Sheild
88 753-04098 Wire Cover
89 791-160428 Cable Clamp
* 791-180852B Spark Plug
* 753-04818 Short Block Assembly (includes 3-14, 65-84)
* 791-180142 Starter Pawl Repair Kit
* Parts not shown
Item
Part No. Description
1 753-04083 Engine Cover
2 791-182339 Engine Cover Screws
3 791-181025 Valve Cover Screw
4 791-182098 Valve Cover
5 791-182099 Valve Cover Gasket
6 791-182340 Rocker Adjustment Nut
7 791-182101 Rocker Arm Pivot
8 791-182100 Rocker Arm
9 791-182341 Rocker Arm Stud
10 791-182103 Valve Spring Retainer
11 791-181038 Valve Spring
12 791-182102 Push Rod Guide
13 791-181033 Push Rod
14 753-04816 Cylinder Assembly (includes 9, 12 & 73)
15 791-182344 Cylinder Screw
16 791-182345 Intake Baffle
17 791-182749 Carburetor Mount Gasket
18 791-181034 Nut
19 791-182347 Carburetor Mount (includes 18)
20 791-182348 Carburetor Mount Screw
21 791-182732 Carburetor Gasket
22 753-04296 Carburetor w/Primer
23 791-181751 O-Ring, Carburetor
24 753-04305 Air Filter/Choke Cover Assembly (includes 32)
25 791-182097 Breather Tube
26 791-181750 Air Filter Mounting Screw
27 791-181757 Air Filter
28 753-1229 Fuel Cap
29 791-182352 Fuel Return Line
30 791-182353 Fuel Pick-Up Line with Filter
31 753-04185 Screw
32 791-182409 Washer
33 753-1230 Fuel Tank Assembly (includes 28-30)
34 791-182356 Fuel Tank Shield
35 753-04297 Throttle Cable
36 791-182358 Muffler Baffle
37 791-181048 Muffler Gasket
38 791-182359 Muffler (includes 37, 39-41)
39 791-180890 Spark Arrestor Screen
40 791-181045 Screen Cover
41 791-181046 Screw
42 791-182361 Muffler Mounting Screw
43 753-04092 Muffler Cover
44 791-182804 Switch Wire Assembly
To Next Page
