DOUBLE BURNER MINI DUO INDUCTION COOKTOP MANUAL P.4
II. Cooktop Installation Continued...
First feed the power wire through the hole and to the location of the power receptacle un-
derneath the cabinet.
The 'h'' overhang on the induction cooker comes with pre-installed foam gasket. Peel o the
adhesive protector on the bottom of the gasket and set the induction cooker into the cut-
out. Gently press down on the induction cook top to secure the adhesive gasket to the coun-
tertop. The cook top should be sitting on the supports previously installed.
For RV use, apply butyl tape instead of the supplied foam tape. Butyl tape will provide ade-
quate adhesion and still allow for removal if the unit needs to be serviced.
