True GDM-23 Installation Manual

............ www.truemfg.com ............
True Food Service Equipment, Inc.
5
5
INSTALLATION / OPERATION INSTRUCTIONS
Toensurethatyourunitworksproperlyfromthefirstday,it
mustbeinstalledproperly.Wehighlyrecommendatrained
refrigerationmechanicandelectricianinstallyourTRUE
equipment.Thecostofaprofessionalinstallationismoney
wellspent.
BeforeyoustarttoinstallyourTRUEunit,carefullyinspectit
forfreightdamage.Ifdamageisdiscovered,immediatelyfilea
claimwiththedeliveryfreightcarrier.
TRUE is not responsible for damage incurred during shipment.
OWNERSHIP
• AdjustableWrench
• PhillipsHeadScrewdriver
• Level
REQUIRED TOOLS
INSTALLATION / OPERATION INSTRUCTIONS
Thefollowingprocedureisrecommendedforuncratingthe
unit:
A. Removetheouterpackaging,(cardboardandbubblesor
styrofoamcornersandclearplastic).Inspectforconcealed
damage.Again,immediatelyfileaclaimwiththefreight
carrierifthereisdamage.
B. Moveyourunitasclosetothefinallocationaspossible
beforeremovingthewoodenskid.
C. Removedoorbracketonswingingglassdoormodels(see
image1-2).Slidingglassdoormodelscontainshipping
blocks(threeforeachdoor).Removethetwostyrofoam
blockstapedtothetopofthedoortracks(seeimage3).
Theshippingblocksareorangeincolorandbyopening
thedooralittletheblockscanberemoved(seeimages
4-6).Donotthrowthebracketorblocksaway.Forfuture
cabinetmovementthebracketandblockswillneedtobe
installedsotheglassdoordoesnotreceiveanydamage.
(Seeimageforbracketandshippingblockremoval)
NOTE
Keys for coolers with door locks are located in warranty packets.
UNCRATING
1 2 3
4 5
6

True GDM-23 Specifications

General

Category	Merchandiser
Capacity	23 cu. ft.
Door Type	Glass
Temperature Range	33°F to 38°F
Refrigerant	R290
Voltage	115V
Horsepower	1/5 HP
