22
a. Using an allen wrench and a socket wrench or open end wrench, remove and set aside the upright pulleys using 2
hex screws, 4 fl at washers, and 2 lock nuts.
b. Using an allen wrench, remove and set aside the main frame pulley using 1 hex screw and 1 lock washer.
1
2
STEP 2—ROUTE CABLE THROUGH UPRIGHT AND MAIN FRAME ASSEMBLIES CONTINUED
96
6
12
13
10
11
To Next Page
