28
STEP 2—ROUTE CABLE THROUGH UPRIGHT AND MAIN FRAME ASSEMBLIES CONTINUED
3
l. Using a ball end allen wrench, remove the 1 hex
screw from the pulley cam.
m. Route the main frame cable around the pulleys and
pulley cam and fasten it into place.
n. Using a ball end allen wrench, reattach the 1 hex
screw you removed previously.
20 20
7
3
To Next Page
