41
ITEM PART DESCRIPTION QTY
1 SPL-10-UPR200X UPRIGHT ASSEMBLY 1
2 SPL-00-RCK001 HOLDER, PHONE 1
3 C1226 PHCS, #10-32 X 1”, BLK 2
Using a #2 Phillips screwdriver, attach the phone holder to the upright assembly using 2 screws.
STEP 6—ATTACH PHONE HOLDER TO UPRIGHT ASSEMBLY
TOOL NEEDED
#2 Phillips Screwdriver
1
2
3
