TAC-27K / TAC-27K-HC-LD: AIR CURTAIN
www.truemfg.com
INSTALLATION TIPS
• Do not place into direct sunlight.
• No HVAC supply or return air vents pushing air into or pulling
air out of cabinet.
• No ceiling fans.
• No doorways.
• Make sure cabinet is level from back-to-back and side-to-side.
NOTE: Check for correct clearance space in back of cabinet and
above. A 4-INCH (102 mm) clearance requirement for the rear of
cabinet and 12-INCH (305 mm) clearance above cabinet.
• Maximum ambient condition 75 degrees and
55% Relative Humidity.
• Place cabinet in an area that will not have any air drafts.
• Excessive airflow around cabinet can effect interior cabinet
airflow (air-curtain).
TAC RECOMMENDED OPERATING CONDITIONS
3 inches
76 mm
8 inches
203 mm
A
I
R
F
L
O
W
A
I
R
F
L
O
W
≤ 75
º
F
≤ 23
º
C
≤ 55%
