CANTILEVER SHELVING INSTALLATION:
A. Install the shelf supports into the shelf standards that are located
in the rear corners of the cabinet. See photos 1 & 2.
Shelf
Clip
Shelf
Shelf
Shelf
Standards
1 2
STANDARD ACCESSORIES
SHELVING INSTALLATION / OPERATION
SHELF INSTALLATION:
A. Hook shelf clips onto shelf standards.
B. Position all four shelf clips equal in distance from the floor for
flat shelves.
C. Lower front of gravity feed TrueTrac organizers to enable
proper feed.
D. Place shelves on shelf clips making sure all corners are seated
properly.
NOTE: Do not load product to where it would over hang the shelf.
