TAC-27K / TAC-27K-HC-LD: AIR CURTAIN
www.truemfg.com
PRODUCT ID STRIP INSTALLATION
A. Take the shelf and turn it around. The back of the shelf should
be facing out. See images 1-2.
B. The product ID strip snaps onto the shelf with the larger
opening of the strip toward the bottom. See images 3-4.
C. After product ID strip is installed tags can be put into the flavor
strip. See image 5.
Turn shelf around.
1 2
Product ID strip install.
4 5
Product ID strip end view
3
