Truma Combi CP Plus User Manual

Truma Combi
®
Quick Reference
CP Plus Functions – Cont.
Select fan speed
OFF – Fan is switched off (If furnace mode OFF)
a) VENT - Circulating air (If furnace mode OFF)
b) ECO - Low fan speed
c) HIGH – High fan speed
d) BOOST – Fast room heating. Available if the
difference between the selected and current
room temperature is >18° F (10° C)
Set clock to current time
Set time switch
Set a start time and end time for room temperature,
water temperature, energy mode and fan speed set
points.
Settings
Index - Show version number of connected device
Bright - Adjust backlighting
Lang - Adjust language
12-24h - 12/24 hour mode
Temp – °F or °C
Offset – Calibrate temp offset
Pr set – Factory reset

Truma Combi CP Plus Specifications

General

Operating voltage	12 V DC
Current consumption (at 12 V)	max. 65 mA
Dimensions (L x W x H)	92 x 103 x 40 mm
Power Supply	12 V DC
Display	LCD
Compatibility	Truma Combi heaters
Mounting	Wall-mounted
Control Functions	fan control
