Truma FrostControl Operating Instructions

8
Intended use
The FrostControl is a power-free safety over-pressure security/
drain valve with a frost guard function. It can be used as an
accessory for the Truma warm water boilers or Trumatic C
and / or also for permanently installed water tanks in caravans
and campers.
As a spare part for the FrostControl that is included in the
scope of delivery of the Truma Combi hot water units.
The FrostControl is suitable for all pressure or submergible
pumps with a pressure level of up to 2.8 bar.
The FrostControl is not suitable as an accessory for
the boiler.
The materials of the FrostControl that come into contact
with water are approved for use with drinking water
(see manufacturer declaration: www.truma.com – Downloads –
Manufacturer Declaration).
Symbols used
This symbol indicates possible hazards.
Information and advice.
FrostControl (safety/drain valve)
Function description
Overpressure safety valve
At an overpressure of around 3.5 bar (e.g. created when heat-
ing up the boiler), the FrostControl opens automatically and
releases the overpressure to the outside intermittently via a
draining connection.
Manual drain valve
The manual drain valve can be opened to drain the water
content.
Frost guard
If there is a risk of frost (at approx. 3 °C ambient temperature),
the FrostControl opens automatically and releases the water in
the boiler to the outside via a draining connection.
The drain valve can only be closed again manually and
the boiler filled again at an ambient temperature of
around 7 °C.
To ensure the system functions correctly, a safety/drain
valve needs to be fitted in the heated room. If this is not
observed, the result may be malfunctions and the drain valve
may open automatically during operation.

Truma FrostControl Specifications

General

Material	Plastic
Protection class	IP 44
Type	FrostControl
Activation	Automatic opening at low temperatures
Operating voltage	12 V
Weight	Approx. 110 g
