TS AR Series User Manual

To comply UL and/or CUL standard,
please keep in mind the following points.
This equipment is to be installed in an enclosure that provides a pollution degree 2
(controlled) environment (Normally, only nonconductive pollution.
However, temporary conductivity caused by condensation may be expected.
These devices are suitable for factory wiring using Nos.2 1 AWG copper wire.
Use 60 75 wire or the equivalent for ARN15 and ARN30.
Use 75 wire or the equivalent for ARN60 and ARN135.
Tighten field wiring terminal (TB1 TB3) to 4.4 lb-in for ARN15 and ARN30.
Tighten field wiring terminal (TB1) to 11.0 lb-in for ARN60 and ARN135.
Tighten field wiring terminal (TB3) to 4.4 lb-in for ARN60 and ARN135.
Suitable for use on a circuit capable of delivering not more than
5000 rms symmetrical amperes, 240 volts maximum,
when protected by circuit breaker having an interrupting rating
not less than 15 rms symmetrical amperes, 240 volts maximum.
Suitable for use on a circuit capable of delivering not more than
5000 rms symmetrical amperes, 240 volts maximum,
when protected by circuit breaker having an interrupting rating
not less than 20 rms symmetrical amperes, 240 volts maximum.
Suitable for use on a circuit capable of delivering not more than
5000 rms symmetrical amperes, 240 volts maximum,
when protected by circuit breaker having an interrupting rating
not less than 30 rms symmetrical amperes, 240 volts maximum.
CAUTION
?
