9
Connector
Description
Remark
1
Micro SD FPC connector
CON9
2
Cradle adapter board connector
CON5
Pin
Description
1
12V
2
12V
3
12V
4
12V
5
12V
6
12V
7
NC
8
NC
9
GND
10
GND
11
GND
12
GND
13
GND
14
GND
3
Battery connector
CON15
