3.7 Replacing Black Mark Sensor

1. Refer to 3.1 to remove printer’s top cover.

2. Refer to 3.6 to remove the media holder.

3. Replacing the black mark sensor by taking it out from the slot as shown.

4. Reassemble the parts in reverse procedures.
