S29 Series Technical Manual
- 16 -
LOAD CELL SPECIFICATIONS
Model No
LC-A-L
Rated Capacity
3~45kg
Sensitivity
2.0±0.002mv/v
Excitation Voltage
15V
IP Level
IP67
Material
Aluminum
Cable
0.3~3m Φ 4mm
Input Resistance
405Ω ±5Ω
Out put Resistance
350Ω ±3Ω
Temperature
Range
-40°C ~ +80°C
Safe overload
150%F.S
Ultimate overload
200%F.S
Error
±0.02%F.S
Creep (30min)
±0.02%F.S
Zero Balance
±1%F.S
