A-2 Model 3786 Ultrafine Water-based Condensation Particle Counter
Front Panel
Display
LED Indicators
Buttons
140 × 32 pixel VF Display provides output of
particle concentration, bar graph history of
particle concentration, particle totalizer,
aerosol flow rate, and operating parameters.
Particle, Status, Flow and Liquid
Display, Totalizer, Pump, Drain/Prime
Back Panel Connections
PC/104 - Ethernet Connector, PC/104 –
Com1 Connector, USB connector, Com Port
connector, Power Connector, Water Source
connector, Vent connector (normally closed),
Water Drain connector, Pump Exhaust
connector, Aerosol Inlet (¼” OD SS tube),
Analog Output BNC
Calibration Interval
Recommended Annually
Power requirements
100–230 VAC 50/60 Hz
125 VA
Dimensions (HWD)
31 cm × 16 cm × 28 cm
(12 in. × 6 in. × 11 in.), not including fill
bottle or bracket
Weight (dry)
5.5 kg (12 lbs.)
Environmental Conditions
Indoor use.
Altitude: Up to 3000 m (10,000 ft).
Ambient Temperature: 10° to 35°C
Ambient Humidity: 0 to 90% RH (non-
condensing).
Over-voltage Category II.
Pollution Degree II.
