Operation 3-33
Export Data Screen
Use the Export Data screen to export sample data to a flash drive.
Select the name of the file and range of data to export. Data is
downloaded into an XML file that can be opened with commonly used
spreadsheet programs.
To Export Data
1. Click the USB drive icon on the Data tab. The Export Data screen
appears.
This file is intended to be used with TrakPro Lite Secure
software and maintains CFR 21 Part 11 compliance.
The file has the extension file name_sec.xml.
This file is intended for user input into Excel for
graphing and data manipulation purposes and has the
extension file name.xml.
If using both file types, both file formats can be
exported. Please note that the data export time is
longer when both file formats are exported.
Do NOT modify the secure file. If the “_SEC” secure file is modified,
TrakPro Lite Secure software will not be able to open the file.
