9.The installation tension table of TSUBAKI timing belts
10. Specification of BDTM201
■Main Body
■Accessories
●BDTM201
●Option
●
●
Power Supply: Two triple A batteries. Alkaline
battery is recommended.
Overall Size: 160（H）× 59（W）× 26（D）
●
●
Mass: 120g
Temperature and humidity range for use and
storage: -10〜-50℃, 80%
（free from condensation）
1） Flexible type sensor
・ Sensor outer diameter: 12.5mm
・ Total length: 170mm
・ Measurable frequency band: 10Hz〜5000Hz
2） Soft case for carrying
・ Capable of containing the body of tension meter,
flexible type sensor etc.
3） Two triple A batteries
4） Operation manual of BDTM201
5） Operating procedure sheet for carrying
6） Inspection acceptance certificate
7） Warranty
Cord type sensor
・ Sensor outer diameter: 12.5mm
・ Total length: 1m
・ Measurable frequency band: 10Hz〜5000Hz
Abouttheinstallationtensionlevelofourtoothbelt,thegapwillnotoccurbetweenBDTM201measurementandtruetensionintherangeof
Note1andNote3.Soitisnotnecessarytosetatensioncompensatingrate.
Note1）Asforthemeasuringinstallationtension,setthebeltonthemachinefirstandmeasuretheaveragetensionofstretchandlooseside
ofthebeltafterspinningseveraltimestomakethemachinerunsmoothly.Ifbothspanshavethedifferenceofmorethan30%,
pleaseadjustthemandmeasureagain.
Note2）Measurewithaspanhavingthelengthmorethan20timesthetoothpitch.
（Becauseahighervaluethanactualisshowedattheshortrangetobeaffectedbytherigidityofthebeltitself.)
Note3）Useabeltwithatensionofatleast1/3oftherecommendedvalueforit.
（Becauseahighervaluethanactualisshowedatthelowtensiontobeaffectedbyrigidityofbeltitself.)
Notethatanextremelylowtensionmaynotbemeasured.
Forinstallationinalongspan,abeltshouldbeinstalledwithtensionclosetoitsmaximuminsomecases.Pleasecontactusfor
details.
Asforexperiencedmachinesinstallthebeltfollowingtheprocedureprovidedforacorrespondingmachine,itiscapableofmanaging
tensionbysettingcyclenumericalvaluewhichapprovedbyBDTM201afterward.
Thank you for choosing our sonic tension meter （BDTM201）.
We guarantee for one year for the main body and six months for the sensor.
If our sonic tension meter （BDTM201） fails due to a manufacturing or workmanship defect
during the period, we repair it free of charge.
Please contact our distributor from which you purchased for the repair.
（See the enclosed warranty.）
When the official approval is required, direct the sensor to a communicator
which emits stable frequency sound from 10 to 5000 Hz, and measure the same way as
measuring tension. The calibration is enabled easily.
In addition, we will calibrate your device for a fee, so please contact us or our sales
agents if needed.
11. Guarantee & Repair Guidelines
①
PX belt
Type P2M P3M P5M P8M P14M
Belt width mm 4 6 10 6 10 15 10 15 20 25 15 20 25 40 60 40 60 80 100 120
Recommended 5.9 9.8 17 20 34 55 108 167 238 304 225 311 382 657 1040 990 1500 2110 2710 3340
Max. 7.8 13 23 26 46 74 147 225 323 412 294 406 510 860 1370 1310 2000 2810 3610 4450
②
PX belt water proof type
Type P5M-W P8M-W
Belt width mm 10 15 25 15 25 40 60
Recommended 108 167 304 225 382 657 1040
Max. 147 225 412 294 510 860 1370
③
Ultra PX belt HC type
Type UP3M-HC UP5M-HC UP8M-HC UP14M-HC
Belt width mm 6 10 15 10 15 20 25 15 20 25 40 60 40 60 80 100 120
Recommended 29 54 88 108 167 238 304 177 244 304 530 834 794 1200 1690 2170 2680
Max. 40 72 118 147 225 323 412 235 324 408 690 1100 1050 1600 2250 2880 3560
④
Ultra PX belt oil proof type
Type UP5M-HA UP8M-HA UP14M-HA
Belt width mm 10 15 20 25 15 20 25 40 60 40 60 80 100 120
Recommended 108 167 238 304 177 244 304 530 834 794 1200 1690 2170 2680
Max. 147 225 323 412 235 324 408 690 1100 1050 1600 2250 2880 3560
⑤
Ultra PX belt HY type
Type UP3M-HY UP5M-HY UP8M-HY UP14M-HY
Belt width mm 6 10 15 10 15 20 25 15 20 25 40 60 40 60 80 100 120
Recommended 39 67 104 125 200 265 355 255 347 445 730 1120 1020 1580 2140 2700 3260
Max. 47 80 125 165 260 350 460 290 394 510 840 1290 1225 1900 2570 3240 3915
Unit
：
N
Unit
：
N
Unit
：
N
Unit
：
N
Unit
：
N
