9.The installation tension table of TSUBAKI timing belts
10. Specification of BDTM201
■Main Body
■Accessories
●BDTM201
●Option
●
●
Power Supply: Two triple A batteries. Alkaline
battery is recommended.
Overall Size: 160（H）× 59（W）× 26（D）
●
●
Mass: 120g
Temperature and humidity range for use and
storage: -10〜-50℃, 80%
（free from condensation）
1） Flexible type sensor
・ Sensor outer diameter: 12.5mm
・ Total length: 170mm
・ Measurable frequency band: 10Hz〜5000Hz
2） Soft case for carrying
・ Capable of containing the body of tension meter,
flexible type sensor etc.
3） Two triple A batteries
4） Operation manual of BDTM201
5） Operating procedure sheet for carrying
6） Inspection acceptance certificate
7） Warranty
Cord type sensor
・ Sensor outer diameter: 12.5mm
・ Total length: 1m
・ Measurable frequency band: 10Hz〜5000Hz
Abouttheinstallationtensionlevelofourtoothbelt,thegapwillnotoccurbetweenBDTM201measurementandtruetensionintherangeof
Note1andNote3.Soitisnotnecessarytosetatensioncompensatingrate.
Note1）Asforthemeasuringinstallationtension,setthebeltonthemachinefirstandmeasuretheaveragetensionofstretchandlooseside
ofthebeltafterspinningseveraltimestomakethemachinerunsmoothly.Ifbothspanshavethedifferenceofmorethan30%,
pleaseadjustthemandmeasureagain.
Note2）Measurewithaspanhavingthelengthmorethan20timesthetoothpitch.
（Becauseahighervaluethanactualisshowedattheshortrangetobeaffectedbytherigidityofthebeltitself.)
Note3）Useabeltwithatensionofatleast1/3oftherecommendedvalueforit.
（Becauseahighervaluethanactualisshowedatthelowtensiontobeaffectedbyrigidityofbeltitself.)
Notethatanextremelylowtensionmaynotbemeasured.
Forinstallationinalongspan,abeltshouldbeinstalledwithtensionclosetoitsmaximuminsomecases.Pleasecontactusfor
details.
Asforexperiencedmachinesinstallthebeltfollowingtheprocedureprovidedforacorrespondingmachine,itiscapableofmanaging
tensionbysettingcyclenumericalvaluewhichapprovedbyBDTM201afterward.
Thank you for choosing our sonic tension meter （BDTM201）.
We guarantee for one year for the main body and six months for the sensor.
If our sonic tension meter （BDTM201） fails due to a manufacturing or workmanship defect
during the period, we repair it free of charge.
Please contact our distributor from which you purchased for the repair.
（See the enclosed warranty.）
When the official approval is required, direct the sensor to a communicator
which emits stable frequency sound from 10 to 5000 Hz, and measure the same way as
measuring tension. The calibration is enabled easily.
In addition, we will calibrate your device for a fee, so please contact us or our sales
agents if needed.
11. Guarantee & Repair Guidelines
