tti Tech PMR-446 - SECTION 7 BOARD LAYOUT; 7-1 MAIN PCB (Top side)

C536 Chip Capasitor 1u
C537 Chip Capasitor 1u
C538 Chip Capasitor 220p
C539 Chip Capasitor 47p
C540 Chip Capasitor 0.0047
C541 Chip Capasitor 0.022
C542 Chip Capasitor 100p
C543 Chip Capasitor 0.068
C544 Chip Capasitor 0.01
C545 Chip Capasitor 0.022
C546 Chip Capasitor 0.1
C547 Chip Capasitor 0.0068
C548 Chip Capasitor 82p
C549 Chip Capasitor 0.1
C550 Chip Capasitor 0.1
C551 Chip Capasitor 100p
C552 Chip Capasitor 0.001
C553 Chip Capasitor 0.01
C554 Chip Capasitor 0.1
C701 Chip Capasitor 0.01
C702
A
lumi. Elec. Capasitor 10u/16V(3x5)
C703 Chip Capasitor 100p
C704 Chip Capasitor 0.22
C705
A
lumi. Elec. Capasitor 22u/16V(5x5)
C706
A
lumi. Elec. Capasitor 220u/10V(8x5)
C707 Chip Capasitor 0.001
C708 Chip Capasitor 0.001
C709 Chip Capasitor 1u
CN201 Housing 53047-0210
CN202 Conector with Wire WC-013
CV301 Chip Trimmer Capasitor 20p.T
CV302 Chip Trimmer Capasitor 10p.T
E201 Capacitor microphone CMP-4542
E202 Speake
r
NR04503N-01
F501 Ceramic filter LTM450HTU
J201 MIC/SPK Jac
k
HSJ1468-01-030
L101 Chip Inductor 10uH(FSLM
)
L301 Chip Inductor 18nH(1608)
L302 Chip Inductor 220nH(LLQ1608)
L303 Chip Inductor 270nH(LLQ1608)
L304 Chip Inductor 18nH(LQN21A)
L305 Chip Inductor 270nH(LLQ1608)
L401 No Moun
t
L402 Chip Inductor 22nH(1608)
L403 Chip Inductor 18nH(1608)
L404 Chip Inductor 22nH(1608)
L405 Chip Inductor 33nH(1608)
L406 Chip Inductor 2.2uH(1608)
L407
A
irwound Coil 0.3-1.2-5T(E2)
L408
A
irwound Coil 0.3-1.0-3T(E2)
L409
A
irwound Coil 0.3-1.3-7T(E2)
L410 Chip Resisto
r
0
L411
A
irwound Coil 0.4-0.9-3T(E2)
L412
A
irwound Coil 0.3-1.0-5T(E2)
L413
A
irwound Coil 0.3-1.2-5T(E2)
L414
A
irwound Coil 0.3-1.2-5T(E2)
L415 Chip Inductor 390nH(LLQ2012)
L416 Chip Inductor 27nH(1608)
L417
A
irwound Coil 0.3-1.3-7T(E2)
L418 Chip Inductor 18nH(1608)
