tti Tech PMR-446 - 7-1 MAIN PCB (Bottom side)

Q101 LED SLM-020ML
T
Q106 CPU M38223M4M-H
P
Q107 No Moun
t
Q108 Digital Transistor KRC404
Q109 IC 24WC04J
Q110 Digital Transistor KRC404
Q111 Digital Transistor KRC404
Q201 Digital Transistor KRA226S
Q202 Digital Transistor KRA226S
Q203 Digital Transistor KRA225S
Q204 Digital Transistor KTC601E
Q205 Digital Transistor KRA404
Q206 Zener diod
e
UDZS5.1B
Q207 Digital Transistor KRA30
5
Q208 IC S-814A50AUC-BD
0
Q209 Diode 1SR154-400
Q210 Diode 1SR154-400
Q301 Transistor BFQ67W
Q302 Diode LL4148
Q303 IC MB15E03S
L
Q304 Transistor KTC4075
Y
Q305 FE
T
2SK508(K52)
Q307 Diode KDS114
Q308 Var. Cap. Diode 1SV270
Q309 Digital Transistor KRC404
Q310 Var. Cap. Diode 1SV217
Q311 Transistor KTC4075
Y
Q312 Zener diod
e
HZK2AL
L
Q313 Digital Transistor KRC404
Q314 Digital Transistor KRA30
5
Q315 Var. Cap. Diode 1SV270
Q316 IC BU4S66
Q401 Diode KDS226
Q402 Transistor BFQ67W
Q403 FE
T
3SK240
Q404 Diode HVU131
Q405 Transistor KTC4080
Y
Q406 Diode HVU131
Q407 FE
T
2SK3476
Q408 Digital Transistor DTC114E
E
Q409 IC NJM2904
V
Q410 Transistor 2SC3356(R24
)
Q411 Digital Transistor DTA144E
E
Q412 Diode 1SS356
Q413 FE
T
2SK3475
Q414 Digital Transistor DTC144E
E
Q415 Transistor BFQ67W
Q501 Diode DA204U
Q502 Diode DA204U
Q503 IC DBL5018
V
Q504 IC LM324M
X
Q505 IC LM324M
X
Q506 FE
T
SSM3K03F
E
Q507 IC LM324M
X
Q508 Digital Transistor KRC404
Q509 Diode 1SS372
Q510 FE
T
SSM3K03F
E
Q701 Transistor 2SA1362G
R
Q702 IC TA7368F
Q703 Digital Transistor KTC601E
15
