Ab/Back Station
ITEM NO. DESCRIPTION PART NO. QTY. ITEM NO. DESCRIPTION PART NO. QTY.
1 ACTUATOR ARM UP0344
1 35 FLAT PHILLIPS SCREW ZINC # 2 X 1/2 BNH1480 2
2 ADJUSTABLE FOOT PIECE UP0338
1 36 FLAT WASHER SAE B/O 3/8" BNH0239 26
3 ADJUSTABLE PULLEY BRACKET UP0127
1 37 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/4 BNH0273 2
4 CIRCULAR PLATE W/AXLE UP0340
1 38 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 BNH0274 5
5 FOAM ROLL 1 X 5 1/2 X 7 1/4 UP0350
2 39 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 BNH0279 2
6 FOAM ROLL 2 X 5 1/2 X 18 UP2031
1 40 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4 BNH0312 6
7 FOOT ROLL TUBE 1 X 16 UP0053
141
HEX KEY ALLOY 3/16" BNH0371 1
8 FOOT ROLL TUBE 1 X 19 7/8 UP4241
142
HEX KEY ALLOY 3/32" BNH0372 1
9 AB/BACK CABLE (AP-5AB) UP2122
143
HEX KEY ALLOY 7/32" BNH0575 1
10 MAIN FRAME UP2119
1 44 NYLON FLAT WASHER 1 X 1 1/4 X 1/16 BNH0393 1
11 PIVOT ARM UP0336
1 45 NYLON INSERT JAM LOCK NUT B/O 3/8-16 BNH0365 5
12 PLATE 1/4 X 2 X 5 UP1759
1 46 NYLON INSERT LOCK NUT B/O 3/8-16 BNH0214 6
13 PLATE 1/4 X 2 X 6 UP1758
1 47 NYLON INSERT LOCK NUT B/O 5/16-18 BNH0215 1
14 PULLEY COVER UP0337
1 48 PLASTIC END CAP W/GROOVE 2" SQ BNH0050 1
15 SEAT PAD UP2111
1 49 PLASTIC INSERT CAP 1 3/4" SQ 10-14 GA BNH0053 3
16 SIDE FRAME UP2120
1 50 PLASTIC INSERT CAP 1" RD 10-12 GA BNH0002 2
17 SWIVEL FOAM ROLL TUBE 22 1/4 UP4242
1 51 PLASTIC INSERT CAP 1" X 2"_ 10-14 GA BNH0005 3
18
ABS PIPE 2 X 19 3/8 BNH1639 1 52 PLASTIC INSERT CAP 2" SQ 10-14 GA BNH0012 1
19
ALUMINUM COLLAR 2.031 ID X 2.584 OD X .500 THK. BNH1520 1 53 PLASTIC TUBE GUIDE W/LIP-TEETH 2 1/4" SQ BNH0059 2
20
ALUMINUM FOOT ROLL HOLDER 1 5/16 ID X 4 1/2 OD BNH1509 4 54 PULL PIN 1/2 X 3 1/2 (YELLOW KNOB) BNH0603 1
21
ALUMINUM FOOT ROLL HOLDER 2 3/8 ID X 4 1/2 OD BNH1510 2 55 PVC 1 X 8 3/4 BNH1611 2
22
ALUMINUM PULLEY 3/8" X 4 1/2" BNH0069 5 56 ROLL PIN Z/P 3/8 X 1 1/2 BNH0483 1
23
ALUMINUM WASHER 3/8 X 2.584 OD X .15 THK. BNH1521 1 57 RUBBER GRIP 1 ID X .125 X 7 1/4 BNH0963 2
24
BALL BEARING #W 516 BNH0628 2 58 SHOULDER BOLT ALLOY 3/8 X 3/4 BNH0718 1
25
BLACK SEAT BELT TYPE 1 ALR RETRACTOR BNH1218 1 59 SMALL TUFFSTUFF LOGO ALUMINUM BNH1323 1
26
BLACK SEAT BELT TYPE 1 BUCKLE BNH1217 1 60 SOCKET SET SCREW ALLOY 10-32 X 1/4 BNH1522 2
27
BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8 BNH0527 2 61 SOCKET SET SCREW ALLOY 10-32 X 1/8 BNH0473 12
28
BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1 BNH0115 4 62 SOCKET SET SCREW ALLOY 3/8-16 X 1/2 BNH0474 2
29
CHROME CAP 2" RD BNH1137 1 63 SPLIT HEX TAP BOLT GR-5 B/O 1/2-13 X 3 1/2 BNH1131 1
30
CHROME WASHER 3/8 X 1 1/2 BNH1015 3 64 SPLIT LOCK WASHER B/O 3/8" BNH0658 4
31
DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1 1/2 BNH0142 1 65 SPLIT LOCK WASHER Z/P 1/2" BNH0572 3
32
DECAL-WARNING KEEP HANDS AND FINGERS... BNH0620 1 66 TURN/PULL PIN W/KNOB AND LOCK BNH0989 1
33
FINISHED HEX NUT B/O 1/2-13 BNH0201 3 67 URETHANE BUMPER 1 3/4 BNH0229 3
34 FLAT PHILLIPS MACHINE SCREW 8-32 X 1/4 BNH0408 1 68 DECAL-EXERCISE AB/BACK STATION BNH1677 1
ITEM NO. DESCRIPTION PART NO. QTY.
22 NYLON PULLEY 4 1/2 RD. BNH0506 5
Ab/Back Station (Deluxe)
All parts same as Ab/Back Station (Deluxe), except for the part listed below
Parts List
Ab/Back Station (Standard)
Parts List
CHART
BOLD FONT = SUB-ASSEMBLY PARTS
REGULAR FONT = HARDWARE
