Step 2 Main Frame Assembly
A
Attach three Pulleys 3/8 X 4 1/2 (#22) to the Side Frame (#16) using hardware shown..
B
Using a rubber mallet, insert the Plastic End Cap W/Groove 2” Sq. (#48) onto the tube-end of the Main Frame (#10).
C
Attach the Side Frame (#16) to the Main Frame (#10) using hardware shown.
Assembly List
Item # Description Qty. Item # Description Qty.
10 MAIN FRAME 1 38 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 3
12 PLATE 1/4 X 2 X 5 1 45 NYLON INSERT JAM LOCK NUT B/O 3/8-16 3
13 PLATE 1/4 X 2 X 6 1 40 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4 4
14 PULLEY COVER 1 46 NYLON INSERT LOCK NUT B/O 3/8-16 4
48 PLASTIC END CAP W/GROOVE 2” SQ 1 36 FLAT WASHER SAE B/O 3/8” 14
22 PULLEY 3/8” X 4 1/2” 3
3
Ab/Back Station
