Step 3 Pivot Arm and Foot Piece Assembly
A
Insert a Nylon Washer 1 X 1 1/4 X 1/16 (#44) onto the axle of the Circular Plate (#4) then insert the Pivot Arm (#11) onto
the axle of the Circular Plate (#4). Next, insert the Circular Plate W/Axle (#4) to the bearing housing of the Side Frame
(#16) then secure the Circular Plate (#4) to the Actuator Arm (#1) using the Roll Pin 3/8 X 1 1/2 (#56). Be sure the Roll
Pin (#56) is aligned with the holes of the Circular Plate (#4) and the Actuator Arm (#1) before hammering it into place.
In addition, make sure the Roll Pin (#56), after hammered in, becomes fl ush on both sides of the Actuator Arm (#1).
B
Attach the Foot Roll Tube 1 X 19 7/8 (#8) to the Adjustable Foot Piece (#2). Next, attach the Foam Rolls 1 X 5 1/2 X
7 1/4 (#5) to the Foot Roll Tube (#8) and secure them into place using hardware shown.
Insert the Assembled Adjustable Foot Piece (#2) into the receptacle of the Main Frame (#10).
5
Ab/Back Station
Assembly List
Item # Description Qty. Item # Description Qty.
1 ACTUATOR ARM 1 28 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1 2
2 ADJUSTABLE FOOT PIECE 1 30 CHROME WASHER 3/8 X 1 1/2 2
4 CIRCULAR PLATE W/AXLE 1 44 NYLON FLAT WASHER 1 X 1 1/4 X 1/16 1
5 FOAM ROLL 1 X 5 1/2 X 7 1/4 2 56 ROLL PIN Z/P 3/8 X 1 1/2 1
8 FOOT ROLL TUBE 1 X 19 7/8 1 62 SOCKET SET SCREW ALLOY 3/8-16 X 1/2 1
11 PIVOT ARM 1 64 SPLIT LOCK WASHER B/O 3/8” 2
To Next Page
