Step 4 Swivel Foam Roll Tube and Seat Pad Assembly
A
Attach the Swivel Foam Roll Tube (#17) to the Pivot Arm (#11) and secure it into place using hardware shown. Next,
insert the Aluminum Collar 2.031 ID (#19) and the Foam Roll 2 X 5 1/2 X 18 (#6) to the Swivel Foam Roll Tube (#17)
and secure them into place using hardware shown.
B
Attach the Seat Pad (#15) to the Main Frame (#13) using hardware shown.
7
Ab/Back Station
Assembly List
Item # Description Qty. Item # Description Qty.
6 FOAM ROLL 2 X 5 1/2 X 18 1 30 CHROME WASHER 3/8 X 1 1/2 1
15 SEAT PAD 1 36 FLAT WASHER SAE B/O 3/8” 2
17 SWIVEL FOAM ROLL TUBE 22 1/4 1 39 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 2
19 ALUMINUM COLLAR 2.031 ID X 2.584 OD 1 60 SOCKET SET SCREW ALLOY 10-32 X 1/4 2
23 ALUMINUM WASHER 3/8 X 2.584 OD X .15 THK. 1 64 SPLIT LOCK WASHER B/O 3/8” 2
28 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1 2
