TuffStuff AXT-225 - Step 8 Assembly List

AXT-225 Deluxe Home Gym www.tustutness.com
23
Step 8 Assembly List
Item # Description Qty.
1 ABDOMINAL CABLE 1
*8 FLOATING PULLEY BRACKET 1
37 7/8 RD. X 1 5/8 LINK 3/16 CABLE 1
38 ABDOMINAL CRUNCH HARNESS 1
39 BLK NYLON PULLEY 12.5MM X 26.3MM X 90MM 1
54 BUTTON HEAD SOCKET CAP SCREW Z/P 3/8-16 X 2 1/2 1
56 CABLE STOPPER SHELL 1 1/2 X 1 3/4 1
62 FLAT WASHER SAE Z/P 3/8” 2
83 NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 1
86 OVAL HEAD PHILLIPS MACHINE SCREW Z/P #10-32 X 1 1/8 1
100 SOCKET CAP SCREW Z/P 3/8-16 X 1 1/4 1
104 SNAP LINK Z/P 8MM X 80MM 1
118 STRAP BRACKET 20 #SF20 STAINLESS STEEL 1
*151 ADJUSTABLE DOUBLE PULLEY BRACKET 1
NOTE:
1. SOME PARTS CUT OUT/NOT SHOWN FOR CLARITY.
2. FOLLOW THE TRIANGLE BALLOONS TO PROPERLY ROUTE THE CABLE.
100%
Fully Tighten
Fully Tighten
Wrench tighten all hardware in this step.
