TuffStuff AXT-5D - Assembly Instructions; Initial Frame Assembly

Step 1
Assembly List
Item # Description Qty.
8 BOTTOM FRAME 1
33 REAR UPRIGHT 1
66 PULLEY 3/8 X 1 X 4 1/2 3
101 FLAT WASHER SAE B/O 3/8” 10
111 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 2
112 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1
121 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 5 1/4 2
134 NYLON INSERT LOCK NUT B/O 3/8-16 2
137 NYLON INSERT JAM LOCK NUT B/O 3/8-16 3
152 RUBBER FOOT FOR 6 X 4 1/4 PLATE 3
4 AXT-5S_AXT-5D AXT- Pro-Style Home Gym
