Loosely Tighten
70%
Loosely tighten all hardware in this step.
DO NOT Fully Tighten. Some component(s)
may need pre-assembly and or alignment
during the assembly process.
Note:
• It is strongly recommended that two people
participate in this assembly step.
• Some parts have been removed for Clarity.
Step 7
Step 7 Assembly List
Item Qty. Description
37 4 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 1 1/2
38 4 SPLIT LOCK WASHER Z/P 1/2"
42 4 FLAT WASHER SAE Z/P 1/2"
*8 1 CHIN UP CROSS BRACE ASSEMBLY
19CDP-300 Dual Adjustable Pulley System W/150 lbs Weight Stacks
www.tuffstuffi tness.com
