TuffStuff CG-9514 - Assembly Step 7: Pad Installation; Attaching Back and Seat Pads

4
60
56
56
19
63
Step 7
Step 7 Assembly List
Item # Description Qty.
4 BACK PAD 1
19 SEAT PAD 1
56 FLAT WASHER SAE Z/P 3/8” 4
60 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 1/4 2
63 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 2
100%
Fully Tighten
Fully Tighten
Wrench tighten all hardware in this step.
CG-9514 Leg Extension/Curlwww.tu stu tness.com22
