COLOR CHART
*BLACK BOLD = PRE-ASSEMBLED COMPONENTS
CHL-610WS
BLACK BOLD = SUBASSEMBLY COMPONENTS
Parts List
BLACK = HARDWARE
REV0
ITEM DESCRIPTION REV. PART NO. QTY. ITEM DESCRIPTION REV. PART NO. QTY.
1 LOWER BASE FRAME 0 UP5201 1
49 COIL CHAIN Z/P 3/16 X 12 LINKS BNH2522 2
2 TOP GUIDE ROD RETAINER 0 UP5209 1
50 HEX KEY 3/16" BNH2542 1
3 TOP HIGH/LOW CROSS BRACE 0 UP5200 1
51 HEX KEY ALLOY 3/32" BNH0372 1
4 SELECTOR POST LT 0 UP5203 1
52 SUPER LUBE TEFLON LUBRICANT 82340 BNH0704 1
5 SELECTOR POST RT 0 UP5222 1 53 ADJUSTABLE CABLE BOLT 0 UP3648 2
6 TOP SWIVEL PULLEY BRACKET 0 UP3637 2 54 ADJUSTABLE FOOT SUPPORT 0 UP5202 1
7 LAT HOLDER 0 UP5212 1 55 CARRIAGE DOUBLE PULLEY BRACKET 0 UP8331 2
8 REINFORCEMENT PLATE W/PULLEY BRACKETS 0 UP8325 1 56 TOP SWIVEL PULLEY BRACKET HOUSING 0 UP5213 2
9 WEIGHT SHIELD 0 UP5215 1
57 10 LB STEEL WEIGHT PLATE BLACK 4 9/16 X 9 7/16 BNH1237 19
10 CARRIAGE LT 0 UP5204 1
58 BALL BEARING 520-2R5 BNH1712 4
11 CARRIAGE RT 0 UP5205 1
59 BRONZE BUSHING 1/2 X 5/8 X 1/2 X 7/8 X 1/8 BNH0528 4
12 ADJUSTABLE PULLEY BRACKET 0 UP5211 1
60 FLAT WASHER SAE Z/P 1/2" BNH2031 6
13 FLOATING ADJUSTABLE PULLEY BRACKET 0 UP5206 2
61 SPLIT HEX TAP BOLT GR-5 B/O 1/2-13 X 3 1/2 BNH1131 2
14 FLOATING DOUBLE PULLEY BRACKET LT 0 UP5207 1
62 NYLON INSERT LOCK NUT Z/P 1/2-13 BNH2029 2
15 FLOATING DOUBLE PULLEY BRACKET RT 0 UP5208 1
63 PLASTIC INSERT CAP 1" RD 10-12 GA BNH0002 4
16 GUIDE ROD 3/4 X 73 5/8 0 UP5210 2
64 PLASTIC INSERT CAP 1 7/8" RD. BNH0003 2
17 REIFORCEMENT PLATE 1/4 X 2 X 4 1/2 0 UP5221 2
65 PLASTIC INSERT CAP 2 X 3 BNH0052 2
18 LAR BAR DOUBLE LINK 0 UP8326 1
66 PLASTIC TUBE GUIDE W/LIP-TEETH 2 1/2" SQ BNH0060 4
19 LOW ROW BAR 20" DOUBLE LINK 0 UP8327 1
67 PUSH PULL PIN 1/2 X 2 7/8 LIGHT SPRING BNH0542 1
20 10 LB TOP PLATE W/22" SLTR BAR 19 BLK WTS ASSY BNH2020 1 68 PUSH PULL PIN 1/2 X 3 1/2 REGULAR BNH0520 2
21 BLACK NYLON PULLEY 3/8 X 1 X 3 1/2 BNH2832 25 69 RETAINING SNAP RING EXT. PLAIN 1 1/4" BNH1718 2
22 NYLON PULLEY 3/8 X 1 X 4 1/2 BLACK BNH2834 8 70 RUBBER FOOT 3 X 4 1/2 BNH0607 1
23 LAT CABLE 0 UP8328 1
71 RUBBER GROMMET 3/4" ID BNH0401 2
24 HIGH/LOW CABLE 0 UP8329 2
72 SOCKET SET SCREW Z/P 10-32 X 1/8 BNH2088 3
25 LOW ROW CABLE 0 UP8330 2
73 URETHANE BUMPER 1 3/4 BNH0229 1
26 NYLON ANKLE STRAP BNH3203 1 74 7/8 RD X 1 5/8 LINK 3/16 CABLE BNH4232 6
27 CONTOUR ERGO HANDLE LONG STRAP BNH2738 2 75 CABLE STOPPER SHELL 1 1/2 X 1 3/4 BNH4230 6
28 CABLE RETAINER BRACKET 0 UP0014 4
76 OVAL HEAD SCREW Z/P #10-32 X 1 1/8 BNH2793 6
29 CABLE RETAINER BRACKET (3 1/2 PULLEY) 0 UP0998 2
77 YELLOW GRIP 1/2 X 4 BNH3059 2
30 RUBBER DONUT 3/4 X 2 1/2 BNH0068 4 78 LABEL-DANGER USE THIS EQUIPMENT ONLY... BNH2903 1
31 SNAP LINK Z/P 8MM X 80MM BNH0065 8 79 LABEL WARNING KEEP BODY, HANDS, 1 1/2 X 2 1/4 BNH2908 1
32 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 3/4 BNH2040 27 80 LABEL CAUTION CHECK PULL-PIN IS FULLY... 1 1/2 X 1 3/8 BNH2912 3
33 SHOULDER BOLT ALLOY 3/8 X 3/4 BNH0718 2 81 LABEL IMPORTANT FOR SMOOTH PERFORMANCE... BNH2916 3
34 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 1/2 BNH2044 2 82 DECAL-WARNING DO NOT USE FOR CHINNING... BNH2923 1
35 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 3/4 BNH2045 2 83 LABEL-IMPORTANT ADJUST CABLE TENSION HERE BNH2924 4
36 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 BNH2046 16 84 LABEL-IMPORTANT FOR SMOOTH PERFORMANCE... BNH2925 1
37 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 5/32 BNH4312 2 85 LABEL-WARNING KEEP BODY, HANDS... BNH2926 1
38 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 1/2 BNH2107 2 86 LABEL-WARNING_SERIOUS INJURY OR DEATH BNH3134 1
39 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 4 3/4 BNH2063 2 87 LABEL-SCHEDULE REPLACEMENT PARTS... BNH3135 1
40 HEX HEAD CAP SCREW GR-5 Z/P 1/4-20 X 3/4 BNH2106 3 88 LABEL-WARRANTY LIGHT COMMERCIAL BNH3136 1
41 FLAT WASHER USS Z/P 1/4" BNH2105 3 89 LABEL-INSPECTIONS RECOMMENDED INSPECTION… BNH3137 1
42 FLAT WASHER SAE Z/P 3/8" BNH2030 108 90 FACILITY SIGN BE ALERT! THE FITNESS EQUIPMENT... BNH3138 1
43 SPLIT LOCK WASHER Z/P 3/8" BNH0658 2 91 LABEL-DANGER CHECK RETAINING NUT... 1.5 X 1 BNH3146 3
44 SPLIT LOCK WASHER Z/P 1/2" BNH0572 5 92 LABEL_TFI SERIAL NO. 2.5 X 1.5 BNH3147 1
45 NYLON INSERT LOCK NUT Z/P 5/16-18 BNH2056 2 93 DECAL NUMBERS 10-200 LBS/KGS 7/8 X 3 YELLOW & BLK BNH4069 1
46 NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 BNH2026 51 94 NYLON BUSHING 25/32 ID X 1 1/16 OD X 29/32 BNH0532 42
47 FINISHED HEX NUT Z/P 1/2-13 BNH0206 7 95 ROLL PIN B/O 3/8 X 2 BNH0661 1
48 SELECTOR PIN W/COIL 3/8 X 4 GOLD KNOB 0 UP3035 1
Parts List
31CHL-610WS High/Low Pulley w/200 Lbs Weight Stack for CSM-600
www.tuffstuffi tness.com
