TuffStuff CHL-610WS - Parts List

Pre-Assembled Components
ITEM DESCRIPTION REV. PART NO. QTY. ITEM DESCRIPTION REV. PART NO. QTY.
*1 LOWER BASE FRAME ASSEMBLY 0 UP5201X1 1 *18 LAR BAR DOUBLE LINK ASM 0 UP8326X1 1
*2 TOP GUIDE ROD RETAINER ASSEMBLY 0 UP5209X1 1 *19 LOW ROW BAR 20" DOUBLE LINK ASM 0 UP8327X1 1
*6 TOP SWIVEL PULLEY BRACKET ASSEMBLY 0 UP3637X1 2 *20 10 LB TOP PLATE W/22" SLTR BAR 19 BLK WTS ASSY BNH2020X1 1
*7 LAT HOLDER ASSEMBLY 0 UP5212X1 1 *23 LAT CABLE ASSEMBLY 0 UP8328X1 1
*8 REINFORCEMENT PLATE W/PULLEY BKTS ASM 0 UP8325X1 1 *24 HIGH/LOW CABLE ASSEMBLY 0 UP8329X1 2
*9 WEIGHT SHIELD ASSEMBLY 0 UP5215X1 1 *25 LOW ROW CABLE ASSEMBLY 0 UP8330X1 2
*10 CARRIAGE LT ASSEMBLY 0 UP5204X1 1 *54 ADJUSTABLE FOOT SUPPORT 0 UP5202X1 1
*11 CARRIAGE RT ASSEMBLY 0 UP5205X1 1 *57 10 LB STEEL WEIGHT PLATE BLK 4 9/16 X 9 7/16 ASM BNH1650 19
*13 FLOATING ADJUSTABLE PULLEY BRACKET ASM 0 UP5206X1 2
Parts List
32 CHL-610WS High/Low Pulley w/200 Lbs Weight Stack for CSM-600
