TuffStuff TDH-345 - Parts List

17
TDH 345 Half Cage Ensembl
Item No. Description Part No. Qty Item No. Description Part No. Qty
1 TOP PULLEY HOUSING UP0722 143CHROME POST RECEPTACLE UP0730 1
2 TRIANGULAR CORNER PLATE UP0101 444BRONZE BUSHING 1 X 1 1/4 X 3/4 BNH0527 4
3 TOP STABILIZER UP0723 145FLAT WASHER SAE 3/8 BNH0239 56
4 BAR HOLDER W/SOLID HOOK UP0704 246NYLON INSERT JAM LOCK NUT 3/8-16 BNH0365 26
5 BAR SAFETY SPOTTER W/SOLID HOOK UP0702 247HEX HEAD CAP SCREW 3/8-16 X 1 BNH0275 4
6 SELECTORIZED UPRIGHT UP0724 248NYLON INSERT LOCK NUT 3/8-16 BNH0214 2
7 ACCESSORY RACK UP0725 149SNAP LINK BNH0065 3
8 PLASTIC END CAP 2 X 3 W/GROOVE BNH0049 4 50 LAT BAR 48" BNH0295 1
9 NYLON INSERT LOCK NUT 1/2 -13 BNH0212 18 51 LOW ROW BAR 20" BNH0294 1
10 FLAT WASHER SAE 1/2 BNH0238 38 52 NYLON INSERT JAM LOCK NUT 1/2-13 BNH0366 1
11 BASE FRAME UP0726 153LAT CABLE UP0618 1
12 HEX HEAD CAP SCREW 1/2-13 X 4 1/4 BNH0291 12 54 LOW ROW CABLE UP0514 1
13 HEX HEAD CAP SCREW 1/2-13 X 3 BNH0264 4 55 LAT BAR HOLDER 2 X 3 UP0096 1
14 HEX HEAD CAP SCREW 1/2-13 X 4 1/2 BNH0265 2 56 HARD GRIP 1 X 6 BNH0296 4
15 PEC DEC HOUSING UP0547 157PLASTIC BUMPER END CAP BNH0412 2
16 PLASTIC INSERT CAP 2" SQ BNH0012 3 58 STEEL BUMPER WASHER 3/8" BNH0498 2
17 PEC DEC ARM PAD UP0548 259COIL CHAIN 3/16 X 21 BNH0017 1
18 BACK PAD UP0112 160PLASTIC TUBE GUIDE 2" SQ BNH0058 2
19 CENTER UPRIGHT UP0727 161PLASTIC TUBE GUIDE 2 1/2 X 3 1/2 BNH0057 8
20 NYLON PULLEY 4 1/2 RD BNH0556 9 62 PUSH-PULL PIN 1/2" BNH0515 1
21 DOUBLE PULLEY PLATE UP0092 263SHOULDER BOLT 3/8 X 3/4 BNH0718 1
22 PEC DEC FLOATING PULLEY BRACKET UP0110 164STRAP BRACKET #20 BNH0562 1
23 BACK PAD PULLEY BRACKET UP0111 165RUBBER BUMPER 3/8 X 1 1/2 BNH0514 3
24 NYLON PULLEY 3 1/2" RD BNH0553 1 66 NYLON INSERT LOCK NUT 5/16-18 BNH0215 1
25 UPPER SWIVEL BRACKET UP0149 167HEX HEAD CAP SCREW 3/8-16 X 3 BNH0264 2
26 PLASTIC INSERT CAP 2" RD BNH0004 2 68 HEX HEAD CAP SCREW 1/4 -20 X 1 1/2 BNH0272 1
27 ADJUSTABLE FOOT SUPPORT UP0109 169NYLON INSERT LOCK NUT 1/4 -20 BNH0213 1
28 BOTTOM ASSEMBLY HOLDER UP0728 170HEX HEAD CAP SCREW 3/8-16 X 1 1/2 BNH0303 1
29 HEX HEAD CAP SCREW 3/8-16 X 2 1/2 BNH0276 4 71 PLASTIC INSERT CAP 1 3/4 SQ. BNH0053 2
30 HEX HEAD CAP SCREW 3/8-16 X 1 3/4 BNH0274 7 72 TURN PULL PIN W/KNOB BNH0929 4
31 CHROME POST UP0729 173REGULAR HEX NUT 1/2-13 BNH0201 1
32 HEX HEAD CAP SCREW 3/8-16 X 4 BNH0285 2 74 DECAL NUMBERS 1-24 BNH0147 2
33 HEX HEAD CAP SCREW 3/8-16 X 2 3/4 BNH0278 8 75 PLASTIC INSERT CAP 1 1/4 SQ. BNH0010 1
34 PYRAMID RUBBER BUMPER BNH0013 2 76 LEG HOLD-DOWN TUBE UP0266 1
35 PLASTIC INSERT CAP 2 X 3 BNH0052 2 77 FOOT ROLL TUBE UP0053 1
36 NYLON STEM BUTTON 3/16 BNH0533 12 78 FOAM FOOT ROLL 7 X 4 X 1 BNH0043 2
37 WEIGHT CARRIAGE 21" UP0118 179FOOT ROLL PLASTIC END CAP 1" BNH0397 2
38 PEC DEC ARM LT UP0545 180L-LOCKING PIN BNH0045 1
39 PEC DEC ARM RT UP0546 181HEX KEY 3/16" BNH0371 1
40 PEC DEC CABLE UP0541 182HEX HEAD CAP SCREW 3/8-16 X 3 1/4 BNH0312 1
41 HEX HEAD CAP SCREW 3/8-16 X 3/4 BNH0283 2 83 HEX HEAD CAP SCREW 3/8-16 X 1 1/4 BNH0273 2
42 EXTERIOR RETAINER RING BHN0419 2
TDH-345
Parts List
COLOR CHART
GRAY= SUB-ASSEMBLY PARTS
BLACK= HARDWARE
COLOR CHART
GRAY= SUB-ASSEMBLY PARTS
BLACK= HARDWARE
