TuffStuff TDH-345 - Introduction; Prior to Assembly; Assembly Notes; Tool Requirements

I
n
t
ro
d
uc
ti
on
Prior to the Assembly of the TDH-345
1. We advise you to consult your local Tuff Stuff retailer if yo
u
should have a question or problem regarding the proper as
-
sembly of this Half Cage Ensemble.
2. Consider the complete surface area of the Half-Cage Ensem
ble. Use the overhead view located on the front page for de
-
signing your layout before assembling. Once the Half-Cag
e
Ensemble has been fully assembled it will be heavy and diffi
-
cult to move. Therefore, you should, assemble the Half-Cag
e
Ensemble in the area where it is to be used upon completion.
3. It is recommended that another person assist you with th
e
assembly of this unit.
4. Neatly organize and identify all parts according to the Part
s
List on page 17, and the Exploded View Diagram on page 18
.
Assembly Notes
1. Read and follow each step of this Assembly Instruction Man
-
ual in sequence. Do not skip ahead, as it will result in an im
-
proper assembly or in having to disassemble parts later.
2. During the assembly of the this unit you will be instructed t
o
leave some Hex Head Cap Screws loosely fastened. Natu
-
rally, they will be fully fastened later in the assembly process
This is done to prevent any difficulty with alignment of som
e
parts during this assembly.
Tool Requirements
1.One 9/16” combination wrench
2.One 3/4” combination wrench
3.One 7/8” combination wrench
4.One 1/2” combination wrench
5.One ratchet
6.One 9/16” socket
7.One 3/4” socket
8.External retaining-ring pliers
9.One rubber mallet
10.One can silicone spray / teflon spray lubricant
11.Windex or household glass cleaner
12.Measuring tape
13.Utility knife
Note: Due to continuing product improvements, specifications and designs are subject to change
without notice.
A
bout the TDH-345 Half Cage Ensemble
C
ongratulations on your new purchase of the TDH-345 Half
C
age Ensemble. This gym is capable of a variety of different
e
xercises, as well as, smooth and user-friendly adjustment fea-
u
res. In addition, this gym has been designed to meet the
n
eeds and performance requirements for a suitable home exer-
c
ise machine. We hope you are completely satisfied with this
p
roduct and wish you many years of enjoyment.
T
uff Stuff Equipment
T
his Tuffstuff product has been built to precise quality standards
a
nd has been carefully packaged to ensure that damage will not
o
ccur during shipment. The Home Lifetime Warranty and signa-
u
re indicating final inspection has been conducted by our line
o
reman, is an expression of our confidence in the complete-
n
ess, the materials, and workmanship of this product.
W
arranty
S
EE A COPY OF WARRANTY ON BACK PAGE.
R
egistration Card
T
o avoid unnecessary delays in warranty service and to insure
h
at a permanent record of your purchase is on file with our fac-
o
ry, be sure to complete the warranty registration card and
end it to Task Industries today.
Note provides information necessary to properly
complete a procedure or information which will
make the procedure easier to understand.
Caution indicates a potentially hazardous situa-
tion, which, if not avoided, may result in minor or
moderate injury. It may also be used to alert
against unsafe practices.
Loosely Fasten provides a instruction to loosely
fasten (ex: hand tighten) a hardware assembly
only. This instruction is intended for the alignment
of hardware components during the assembly
process.
Fully Fasten provides a instruction to fully fasten
(ex: completely tighten) a hardware assembly.
A
bout the Icons
T
he icons displayed in this Owner’s Manual are used to facilitate
he correct assembly and safe use of this Product, as-well-as to
p
revent injury to yourself or anyone else.
LOOSELY FASTEN
FULLY FASTEN
Hardware Measurement Diagram
TDH 345 Half Cage Ensembl
1
. Maximum Wt. Capacity - 600 Lbs.
. Total Machine Weight - 405 Lbs.
. Footprint (LWH) See Front Page
S
pecifications
