74
J5F
1 M6x15 DIN 7985 Screw 4
2 533 4061 Base frame end cap 2
4 533 4072 Snap bushing 2
5 M6x25 DIN 7985 Screw 10
6 533 4065 PVC foot 2
7 M8x50 ISO 7380 Dome head bolt 3
8 523 4044 Wheel sleeve 4
9 533 4062 Base frame wheel 2
*10 M8 DIN 6798 I Star washer (* 14 pcs) 24
11 M8 DIN 125 Washer 12
12 M8 DIN 985 Nylock nut 12
13 533 4064 Base frame end cap 2
14 103 4056 Base frame 1
15 M5x40 DIN 912 Head allen key screw 2
16 533 4071 Lock pin cap, L 1
19 223 4004 Cable, release (incl. 17, 18) 1
20 533 4074 Frame end cap, R 1
21 533 4053 Rubber bumper 6
24 373 4008 Release lever (incl. 22, 23, 25) 1
26 533 4063 Moving wheel 2
27 523 4041 Moving wheel sleeve 2
28 103 4055 Main frame 1
*29 M8x15 ISO 7380 Dome head bolt 19
31 503 4043 Incline support link (incl. 30) 1
32 533 4066 Incline wheel 2
33 M8x30 ISO 7380 Dome head bolt 6
34 503 4044 Incline wheel bracket 1
35 533 4069 Track slider 2
36 533 4068 Bushing spacer 2
37 533 4067 Connection tube bushing 2
38 343 4017 Moving shaft 1
39 103 4057 Incline structure frame 1
40 16 DIN 471 E-clip 2
41 343 4015 Incline linkage shaft 1
42 343 4018 Fixed shaft 1
43 103 4058 H-frame 1
44 533 4070 Spacer 8
45 M4x8 DIN 7985 Screw 16
46 163 4007 Gas shock 2
47 M6x40 DIN 912 Screw 2
48 533 4073 Track stopper 2
49 M6 DIN 6798 I Star washer 2
51 653 4055 Nut (incl. 50) 1
52 343 4016 Lift motor shaft 1
53 813 4024 Lift motor, 230V (50-52, 54) 1
- 813 4028 Lift motor, 110V (50-52, 54) 1
54 2 DIN 11024 Pin 1
55 403 4110 Power board, 230V 1
- 403 4123 Power board, 110V 1
56 643 4006 Off power spring 1
57 523 4046 Off power sleeve 1
58 503 4048 Off power bracket 1
60 403 4128 Micro switch (incl.59, 61, 63) 1
62 M4x10 DIN 7985 Screw 2
64 M5x10 DIN 7985 Screw 6
65 M5 DIN 127 Spring washer 2
66 403 4106 Sensor cable 1
67 813 4026 Motor, 230V 1
- 813 4027 Motor, 110V 1
68 503 4046 Motor bracket 1
69 M8x20 DIN 912 Head allen key bolt 2
70 653 4056 Screw 4
71 M8x50 DIN 912 Head allen key bolt 3
72 M8 DIN 934 Nut 1
73 403 4120 Circuit breaker, 230V 1
- 403 4124 Circuit breaker, 110V 1
74 M4x6 DIN 7985 Phillips head screw 2
75 403 4121 Mains switch 1
76 403 4118 Capacitor, 230 V 1
- 403 4139 Capacitor, 110 V 1
77 403 4122 Mains cable socket 1
78 173 4082 Motor cover 1
79 M6 DIN 127 Spring washer 2
80 M8x40 DIN 912 Head allen key bolt 1
81 M8x30 DIN 912 Head allen key bolt 1
82 M8 DIN 137 B Curve washer 1
83 523 4052 Front roller 1
84 443 4017 Drive belt 1
85 443 4019 Running belt 1
86 523 4053 Rear roller 1
87 M4x15 DIN 7985 Screw 8
88 653 4059 Washer 8
89 433 4037 Running deck 1
90 503 4051 Deck bracket 2
91 M5x10 DIN 7985 Screw 4
92 M6x10 DIN 912 Head allen key screw 2
93 433 4033 Anti-slip mat (incl. 94) 1
95 433 4038 Side landing (incl. 96) 2
97 173 4068 Right rear end cap (incl. 98) 1
99 M4x20 DIN 7985 Screw 6
100 M6x10 DIN 7985 Screw 2
102 173 4069 Left rear end cap (incl. 101) 1
103 M8x65 DIN 912 Head allen key bolt 2
104 233 4027 User interface, EUR (incl. 129) 1
- 233 4034 User interface, USA (incl. 129) 1
105 173 4085 Console rubber, pair (incl.120) 1
106 173 4084 Handle bar cover, R pair 1
107 213 4015 Handle grip 2
108 533 4075 Handlebar end cap 2
109 203 4047 Upright post welded, R 1
110 403 4127 Cable, set (incl. 3) 1
111 203 4048 Upright post welded, L 1
*112 M8x55 ISO 7380 Dome head bolt 1
113 173 4083 Handle bar cover, L pair 1
115 2,9x15 DIN 7981 Screw 6
116 203 4049 Horizontal bar (incl. 128) 1
118 403 4099 Safety key 1
121 3,5x15 DIN 7982 Screw 8
122 M3x6 DIN 7985 Screw 4
123 M3 DIN 137 B Spring washer 4
124 403 4116 EMI fi lter, EUR (incl. 125) 1
126 M4 DIN 6798 I Star washer 2
127 813 4025 Choke, EUR 1
128 213 4019 Handle grip horizontal 1
129 233 4030 Membrane 1
130 173 4076 Lower cover 1
* 403 4104 Power cable, EUR 1
* 403 4125 Power cable, USA 1
* 403 4126 Power cable, GB 1
* 423 4093 Lable set 1
* 553 4020 Assembly kit (incl *) 1
- 583 4028 Owner´s manual 1
